Borgeson needle bearing universal joints are machined in our factory on state of the art cnc equipment from steel stainless steel or aluminum. This can cause hard spots in steering or premature wear on the joint bearings.
Ididit S What Not To Do When Attaching A Shaft To A Column
Steering u joint alignment. If your steering system requires three or more u joints start by positioning the middle u joint somewhere near the center at close to its maximum angle swiveling the components to find the fit. By the way borgeson u joints are available machined out of different materials but theyre. Determine whether you will need a two or three u joint system. If its a relatively straight shot and your universal joint angle will be less than 30 then you can use two universal joints and one piece of shaft. Angles over 35 can be accommodated by using a double universal joint. This will be dictated by the angle of the universal joints and the routing of the column to the steering gear.
Weve got steel stainless steel aluminum and chromoly steering shaft universal joints in a variety of sizes and spline counts. With a column at an incorrect angle it can cause binding due to extreme angles which can turn a relatively simple two u joint system into a three or four u joint setup. If the joints are not properly phased they will operate at varying speeds throughout each revolution which can cause second order vibrations. In extreme cases the column can be out of position and alignment with the. Replace your worn factory steering u joint or finish off your custom steering system with top brand u joints from summit racing. If the u joint angle exceeds 35 degrees consider a double jointed u joint like pn 910 3247.
The vibration can lead to increased wear and potential damage to the assembly and failure of the application. Choose from flaming river ididit unisteer performance howe racing heidts detroit. The instruction in general is to assemble everything rack and column with loose fasteners then tighten the u joint bolts first followed by tightening the steering column bottom flange bolts and then the column top cradle bolts in that order. The biggest effect will be in your steering linkage universal joints and intermediate shafts. A second u joint is attached to the steering gear thus providing both a starting and ending point. Borgeson single universal joints will operate smoothly at angles up to 35.
Phasing is the process of aligning the universal joint yokes on both ends of the drive shaft or double u jointin a parallel fashion. If a single u joint is installed we recommended not surpassing a 35 degree angle.
Gallery of Steering U Joint Alignment
