Old 3 way switch. Wire nuts and a voltage tic do wonders on. Turn off the power to the switch at the circuit or fuse panel. 3 way switches are normally wired with power on one switch to that odd screw and the other 3 way gets the light connected to the odd screw. The new switch just has l1 l2 loop and com. Unscrew and remove the switch plate. In a hallway or large room for example installing three way switches at both ends lets you turn the light fixture on or off from both locations.
Such markings are not needed with this type of switch as they are. There are three screw terminals on the body of the switch in addition to the green grounding. The old switch had four wires going into l1 l2 l3 and l4. A three way wall switch is a common type of light switch that makes it possible to control a ceiling light or other electrical fixture from two different locations in a room. Test the switches with a voltage tester to ensure the power is off. Connect the two remaining traveler wires to the two brass or light colored screws.
Re wiring 3 way light switch hi guyscould really do with some advice for replacing a 3 way single light switch. To replace a three way switch follow these steps. There are old existing 3 way electrical switch installations that do not follow acceptable industry practice or electrical code requirements. How to replace your old outdated 3 way light switches step 1. Then use a voltage tester to make sure that the circuit is dead. Connect the ground wire to the green screw.
The other 2 wires just transfer power back and forth so that each switch can turn the light on and off at the opposite intervals. Old 3 way wiring 1 identify line side cable both hot and neutral they become big clues. The name refers to the fact that these switches have three terminal screws. 2 go to david e. Changing a 3 way switch to a wifi smart switch can be tricky. There are two clear giveaways that identify a switch as being a three way type.
Unscrew the three way switch you suspect. Shapiros old electrical wiring page 57 for the wiring diagram. That is why it is important to identify the function of the wires for 3 way electrical light switches. The necessary supplies though are critical so make. The most basic three way switch setup has two switches that connect and control one light. When wiring a 3 way switch first screw the terminal screws of the new switch until they are difficult to turn.
Connect the wire marked common to the black or dark colored screw. Start by turning off the power to the circuit youll be working on at the main electrical panel. Remove the cover plate from the switch box with a slotted screwdriver. There are no onoff markings on the switch toggle.
