The larger piston like the one used in the legend series calipers typically require a master cylinder with a larger bore size while the smaller but multi piston calipers require a smaller bore size master cylinder with slightly less volume but more overall pressure. The cast iron single piston gm calipers either the chevelle type or the metric type usually need a 1 bore master cylinder for manual and a 1 18 bore for power.
Video How Master Cylinder Bore Size Affects Braking
What size master cylinder bore do i need. For instance if you were using the typical gm calipers that a lot of us use from either a chevelle or a malibu you need a 1 bore for manual brakes and a 1 18 bore for power brakes. A 78 bore master cylinder has a bore area of 6 inches squared. Drum are based on the fact that disc brake systems dont have adjustment. This helps free the car up getting in the corner and allows the car to carry more speed into the corner. I would call wilwood or a dealer morrison probably is one. If the brake system is manual no power booster the master cylinder bore diameter should be less than 1 in otherwise a very hard pedal will result.
A decrease in master cylinder bore area produced a proportionate. Since drum brakes require the use of residual pressure valves the original drum master cylinders had residual valves built into the outlets. Even though we used the 69 camaro and its related boostermaster combos for. A power brake master cylinder will typically feature a larger bore diameter than a manual master cylinder. Most dirt track racers with a dual master cylinder set up choose to run the 78 bore master cylinder to the rear and the 1 bore master cylinder to the front. Common master cylinder bore sizesarea diameter in inches 062 075 081 088 100 112 areapiston inches sq 031 044 052 060 079 099 the midsize gm caliper i am using on the front has a 275 bore caliper which equals 594 area according to the chart above.
If we apply that same 100 pounds of force to the 78 master cylinder using the formula 100 divided by 6 that same 100 pounds of force from the pedal will generate 1667 psi. Typically a drum brake master will be smaller than a disc master and the fluid reservoir chambers will be equal in size. You need to match the master cylinder to the calipers you have. The recommendations for disc vs. The fluid level drops as the pads wear. By calculating the area in inches squared bore x bore x 785 for any master cylinder size you can calculate how much pressure change would be affected by a bore size change.
