Wires are color coded to avoid wiring errors that may lead to accidents and electrical inconvenience to household the whole block orin some casesthe town. Beyond that are general industry accepted rules about wire color that indicate their purpose.
Pamia Tech Tip Electrical Wiring Color Codes
Outlet wiring color code. All nm cables contain the basic black insulation and white insulation wires plus the bare copper or green insulated ground wire. These are the wire color coding standards that are used in the united states. The common color code for three phase in on or behind the wall electrical wiring is shown below. The wires inside an nm sheathed cable are color coded to make it possible to identify each one at both ends of the cable and wire correctly. Installing a 115 volt plug is one of the most basic of home wiring tasks. Just keep in mind the basic electrical color code.
Its possible to link two red wires together or a red wire to a black wire. In addition red wires are used to connect hardwired smoke detectors to the homes power system. The national electrical code nec says that white or gray must be used for neutral conductors and that bare copper or green wires must be used as ground wires. Ground ground wiring should be green or green with a yellow stripe. While wires in these colors carry power they are not used in typical outlet wiring. Black goes on brass terminals white goes on chrome ones and green or bare goes on the green terminal.
Phase 2 phase 2 wiring should be orange. In three phase power supply the combination of black red and blue wires for power conductors are used for 120240v ac whereas the combination of brown orange and yellow wires for power conductors are used for 277480 v ac. Most of these wires are utilized as switch legs and may feed an outlet as well. Blue and yellow electrical wires. Black wires are specifically used for hot wires and voltage transmissions. The spruce 2018.
Neutral neutral wires should be grey. Phase 1 phase 1 wiring should be brown. Phase 3 phase 3 wiring should be yellow. Always shut off the power and check the wires with a voltage tester. The codes shown are examples only and may not be current or accurate for your application or jurisdiction. Introduction to electrical codes for outlets and receptacles nec 210 7 receptacle outlets shall be of the grounding type be effectively grounded and have proper polarity.
