The best placement for static ram air engine oil cooler non electric fan equipped style is in a location exposed to a maximum amount of airflow allowing the cooler to operate as efficiently as. For extreme cooling issues you should consider a cast deep oil pan for the transmission.
Oil Cooler Options Amp Mounting Position S2ki Honda S2000 Forums
Oil cooler mounting position. 2b three per location and bolt to panel or brackets using bolts and lock nuts provided. Position cooler over brackets or panel to which cooler is to be attached. As many people have oil coolers with the cooler fittings facing down toward the ground as modshacks diy shows this is a potentially very important issue. Transfer centers of holes onto brackets or sheet metal and drill 516 holes. Should be taken to mount the cooler at least ¼ in from the radiator or condenser. If you unplug the acc sensor do not turn the key on and make sure you plug it back in fully.
This means that a good quantity of the oil in the cooler will backflow to the oil pan when the system isnt pressurized engine is off. Installing the dinan oil cooler kit. When you loosen the radiator support assembly to install the new right side lower radiator mount oil cooler mounts mark the position of the nuts that hold it to the frame so you can install it in the same position. Fit remaining gatorclips to cooler per fig. The cooler is mounted above the oil pan. The cooler may be mounted in any position and oil may flow through the cooler in either direction.
The mounting should be rigid and should never allow the cooler to contact either the radiator or condenser. However use care and common sense to select a mounting. When mounting the cooler with the fittings on the right or left side the lower fitting must be the inlet with the top fitting routing the fluid back to the transmission.
