Secure the wires by twisting one wire nut onto each pair of wires. Since the float switches are are already tied together in series the current is now going through both so if one fails trips either one of them the condenser low voltage breaks which means no more refrigerant can flow so no more condensate water can.
Ha 7938 Wiring Diagram For Condensate Pump Schematic Wiring
Hvac float switch wiring diagram. Step 4 twist the end of the second float switch lead to the appliances load wire. Ac service tech llc. Cookie consent we use cookies to improve your website experience. By continuing to use the website you consent to our use of cookies. If the float switch. Float switch install instructions condensate drain pan attic air conditioner drip pan condensate overflow shut off switches electronic condensate overflow switch manualzzha 7938 wiring diagram for condensate pump schematicsha hvac overflow flood detection and preventative shutdownfloat switch install instructions needed hvac diy chatroomcondensate switch controversy hvacwhat is an ac float switch and why do i read more.
Hvac installing a float switch duration. Cut the red r terminal wire running the thermostat with a pair of wire cutters. Understanding basic electrical wiring and components of air conditioning systems duration. Hvac installation training basics for condensate safety switches low voltage wiring drain trap. Break one of the two wires to the condenser as in cut it open and wire nut the one line from one of the float switches to one side small orange or blue or gray wire nut and wire nut the other side from the other float switch to the other. If the float switch protects an air conditioning system disconnect the furnaces transformer wire that connects to the red thermostat wire and then connect the float switch lead to the transformers wire.
Twist one end of each float switch wire to one of the exposed section of the cut r terminal wire. Here you can join over 150000 hvac professionals enthusiasts from around the world. Hvac wiring hvac wiring pdf wiring a hvac contactor wiring a hvac transformer hvac panel wiring diagram hvac wiring float switch residential hvac wiring diagram g 21 posts related to hvac wiring diagrams 101. If the float switch operates a pump connect the lead to the wall outlets plug wire or the wire connected to the circuit breaker. In this video i will show you the submersible starter power wiring connection diagram submersible starter connection wiring. Goettl las vegas air conditioning inc.
To learn about our use of cookies and how you can manage your cookie settings please see our cookie policy. Then screw a wire nut over the ends of the wires. Strip 12 inch of insulation from each end of the cut terminal wire and the end of each float switch wire with a pair of wire strippers.
