How to wire driving lights using a relay. That is kind of cryptic isnt it. How to wire aux lights fog lights led lights light bar or anything else to a switched circuit in your vehicle the right way. The relay will have 4 points on it marked 30 87 85 and 86. With our wiring harness all you need to do is cut the wire coming from the switch to the 30 prong on the relay and wire it to your high beam lead or your backup light wire. It connects to the. To fit your new lights follow these steps.
Ive been doing all my own wiring as i couldnt find a suitable harness heres what ive done so far. Find a suitable place on your dashboard for the switch. My project for the long weekend was to wire up a lightbar on my ve ute i was able to get everything to work except the turning on and off with the highbeams part. How to install driving lights overview. In this case you need to wire the dash switch in between the trigger current ie. The switch will activate the driving lights when you turn on.
This listing is features one set new relay wiring harness with onoff switch universal fit for led daytime running lights off road driving lights and led work lights. Attach the black wires from the lamps. The line you spliced off your high beam wire or your backup light wire. The left side is the pin out of the point is sticking out from at the bottom and the the right side is showing a schematic representation of the relay circuitry. Connect the other end of the green wire to the. De stickers on etsy.
Use the following procedure. Mount the relay in the engine bay placing it as close to the battery as possible while avoiding areas of excessive. Harness wiring locate the low beam or high beam light lead on one headlamp by using a circuit tester. 30 is your power source for your light. By default this switch is open so the current cannot get from the battery to your lights. Run a.
Do not connect the power to the battery until all wiring is done. Fog light driving light daytime light. Leave at least one foot of wire hanging after the tape to leave enough slack for the connection to the lights. Want to support de. Scotch lock the bare end of the green wire to the low or high beam lead. 1 x relay switch control wiring harness.
Follow the relays wiring schematic when connecting the wires to the relay one of the relays terminals goes to ground. The switch included gives more flexibility controlling the lights. Then run a heavy gauge wire from the battery to the relay placing a 30 amp fuse in line very close to the battery. Route the power supply wire the power supply wire will run from the high beam relay wiring harness to the driving or fog lights. How to wire your light using a relay.
