Connect a 10 gauge wire from the output stud on the alternator back to the positive battery terminal. This connection can be made at the starter relay also as long as it connects to the same terminal as the positive cable from the battery.
Kc 7131 Wiring Diagram One Wire Alternator Schematic Wiring
How to wire a one wire alternator. Install a 10 gauge wire to this terminal with a ring connector and run the wire to the back of the alternator. See all 9 photos. One wire alternator install alternative energy source improving the charging system with a one wire alternator. Make sure that the battery is fully charged. Make both connections with a solderless ring terminal. Alternator basics tips tricks 1 wire models of gm ford mopar from 1960 1980s autorestomod episo duration.
Autorestomod manic mechanic gasoline media 35312 views. This video shows you how to wire a single wire alternator on tractors. Follow the battery positive cable from the battery to where it is connected on the starter relay. Remove cover to plug in and use your original wire harness. Connect this wire to the the insulated stud output terminal on the back of the alternator with another ring connector. Reconnect the negative cable to the battery.
We are showing this example on an mf 35 deluxe tractor but the same wiring will work on all single wire alternators. 1 wire alternators 1 wire alternators require only 1 wire to operate. Simply run one wire from the alternator battery terminal to the positive terminal of the battery or to the starter solenoid main lug which is connected to the positive battery post.
